Submersible mixers

The submersible mixer is specially designed for a wide range of applications. The agitator is equipped with an optimized propeller, which guarantees a good balance between blasting, flow and power requirements. The submersible motor is optimal for completely submerged use in liquid manure, sewage and biogas substrates. The motor protection type is IP68. The motors are available in a power range from 7,5kW to 30kW. A mechanical seal and gearbox for reduction from motor to propeller speed (planetary or helical gearbox) ensures best performance.

The manure mixer is equipped with sensors for sealing and temperature monitoring. The connection of the sealing and temperature monitoring is only possible with special suitable motor protection switches. A warranty is given only with matching Agriprom switches.

Specifications
Motor nominal power: 11 kW, 15 kW, 18,5 kW, 22 kW, 30 kW (choice out of 5 different polyphase motors)
Protection class: IP68, isolating class F
Rated speed: 330-350U/min
Operating voltage: 400 V 3-, 50 Hz
Sealing: silicium carbide mechanical seal
Oil qty: 0,75-0,90 L
Lubrication oil type: ISO VG220
